RHEED

  • Fundamental unit of PASCAL Reflection High-Energy Electron Diffraction (RHEED) consists a compact size electron-gun with mounting via CF1.33″ (ICF34) flange.
  • The compact size e-gun brings easy mount to a vacuum chamber or easy maintenance.
  • Reflection High-Energy Electron Diffraction (RHEED), a reflection high-energy electron diffraction equipment, consists of a CF 1.33″” flange mount and a small size electron gun.
  • The compact electron gun enables easy maintenance and allows parallel operation of other optional devices under high pressure conditions or when observing scanning plane samples of the electron beam.

SPECS

○ Feature * 200 deg C bakable for UHV* Compact HV power supply : up to 30 kV* Single differential pumping : up to 1Pa* Double-stage differential pumping (option) for high-pressure : up to 100Pa* Electron-beam parallel scanning (option) : Multiple diffraction monitor at same condition ○ Specication

* Electron-gun

Acceleration voltage 30 kV max (25 kV rated).
Filament Tungsten (W), hair-pin shape.
Electron beam diameter Phi 0.5 mm
Deflection XY-axes by coil
Baking 200 deg C bakable
Dimension / Mount L 310 mm, phi 43 mm / CF1.33" (ICF34) mount
Differential pumping port CF1.33" (ICF34)

* High-voltage power supply

Output high-voltage 0-30 kV
Stability Less than 0.5 %
Remote control All parameters for e-gun operation by handy console
Dimension W480 mm x D400 mm x H150 mm (JIS rack mount)
Power inlet AC 100V, 1-phase

* Fluorescent screen                                                    Specifications are subject to change for improvement without notice

Screen CF6" (ICF152) or CF8" (ICF203) mount with shutter
